Quick Details
Profile
| No. |
Main Parameters |
Roll Forming Mill Parameters |
| 1. |
Decoiler |
Manual/Hydraulic for options |
Forming Stations |
14-step |
| 2. |
Cut-to-Length Tolerance |
≤±1 mm |
Base |
H400 |
| 3. |
Material Thickness |
0.3-0.6mm |
Side Wall Thickness |
Q235 t18mm |
| 4. |
Form Speed |
20m/min |
Shaft Diameter |
ф65mm |
| 5. |
Application Material |
Prepainted galvanized steel(PPGI) |
Main Motor Power |
5.5 KW |
| 6. |
Yield Strength |
Q235-345Mpa |
Screw Bolts |
Grade 8.8 |
| 7. |
Hydraulic Motor |
5.5 KW |
Cutting Tool Material |
Cr12MoV, heat treatment to HRC58-62 degree |
| 8. |
Effective Size |
As Customer Design |
Roller |
45# steel |
| 9. |
Control System |
PLC Control System |
Processing Mode |
CNC lathes, Hear Treatment, hard Chrome Coated, with thickness 0.04mm |
| 10. |
Testing Material |
BMS Will Provide The Size of Feeding Material to Purchase That 2 Weeks Before Machine Testing |
After-sale service of Decoration Panel Roll Forming Machine YX12-145
1. The warranty of Decoration Panel Roll Forming Machine YX12-145 is one year after the client receives the machine. Within the one year, we will courier the replacement parts to the client free of charge.
2. We offer technical support for the entire life of our machines.
3. We can send our technicians to install and train the workers in the clients’ factories with extra cost.
