Profile
| No. |
Main Parameters |
Roll Forming Mill Parameters |
| 1. |
Material Thickness |
0.3-0.8mm |
Forming Stations |
18-step |
| 2. |
Feeding Width |
925mm |
Body Frame |
H400 |
| 3. |
Application Material |
GI/PPGI |
Reducer |
R series |
| 4. |
Electrical Standard |
380V/60Hz/3Ph |
Shaft Diameter |
45# Steel, φ75mm |
| 5. |
Manual Decoiler Diameter |
508±30 mm |
Main Motor Power |
7.5 KW |
| 6. |
Yield Strength |
245-550Mpa |
Screw Bolts |
Grade 8.8 |
| 7. |
Forming Speed |
15-20m/min |
Effective Width |
686mm |
| 8. |
Control System |
PLC Control System |
Roller |
45# Steel, CNC Lathes, Hear Treatment, HRC58-62 |
| 9. |
Hydraulic Motor |
4KW |
Machine Color |
Blue+Black+Orange |
| 10. |
Testing Material |
BMS Will Provide The Size of Feeding Material to Purchase that 2 Weeks Before Machine Testing |
Work Flow
Twin Head De-coiler(5Tons) → Feeding Guide Device → Main Roll Forming Mill → Hydraulic Post Cutter → PLC Control System →Exit Rack
