Profile
| No. |
Main Parameters |
Roll Forming Mill Parameters |
| 1. |
Material Thickness |
1.5-3.0mm |
Forming Stations |
28-steps |
| 2. |
Feeding Width |
130-200 |
Body Frame |
H450 |
| 3. |
Application Material |
SuperDyma/Galvanized sheet/Black strip |
Side Wall Thickness |
18mm |
| 4. |
Electrical Standard |
380V50Hz/3Ph |
Shaft Diameter |
45# Steel, φ85mm |
| 5. |
Manual Decoiler Diameter |
3T-500MM |
Main Motor Power |
15KW |
| 6. |
Yield Strength |
345-550Mpa |
Screw Bolts |
Grade 8.8 |
| 7. |
Forming Speed |
0-35m/min |
Effective Width |
According to the drawing |
| 8. |
Control System |
PLC Control System |
Roller |
Cr12 Steel,precision machined |
| 9. |
Hydraulic Motor |
5.5KW |
Machine Color |
Blue+Black+Orange |
| 10. |
Testing Material |
BMS Will Provide The Size of Feeding Material to Purchase that 2 Weeks Before Machine Testing |
Work Flow
Manual Decoiler (5Tons) → Leveling Device/Punching Device→ Main Roll Forming Mill → Automatic non-stop sawing device → PLC Control System → Hydraulic Station→Exit Rack*2
