Profile
1.This Machine Is For The Project Of Fortune 500 Company Cscme (China State Construction Engineering Corporation) .
2.It Is Equipped With Cooling And Lubricating Devices To Reduce Friction Resistance, Prolong The Service Life Of Rollers And Ensure The Good Surface Of Roll Formed Profile.
3.The top angle is made adjustable both for 75 and 90°3 which keep flexibility for project installation: 1 machine for 2 profiles.
4. The Machine Meets The Requirements Of The China National Standard《Gb/T34385-2017 General Technical Specifications For Cold Roll Forming Machinery.
Technical specifications
Main Motor: Double Servo Motors (22KW+22KW); Brand: Huichuan
Speed Reduce Motor: K Series
Chain: Polaroid
All the screw bolts with grade 8.8 (Cheap factories use low grade 4.8) to ensure fix the
machine structure tightly and long life during the machine long time running.
Work Flow
Hydraulic Uncoiler (Self-Provided ) → Feeding Guide Device →Lubricant Device → Leveling Device → Roll Forming（Cold Water Device）→ Hydraulic Post Punching Device→ Hydraulic Post Cutting Device → Exit Rack*2
